Power Multi Core Armoured Cable CU/XLPE/SWA/PVC – Sector Shape Conductors – BS 5467
MESC CU/XLPE/SWA/PVC sector shape armoured power cable BS 5467, 3–4 core, 25–95mm², 600/1000V. Industrial & utility power distribution. UAE supplier.
MESC Power Multi Core Armoured Cable (CU/XLPE/SWA/PVC, BS 5467) with stranded compacted sector-shape conductors is designed for high current power distribution where space efficiency matters. The sector shape reduces the overall cable diameter compared to circular conductors at the same conductor cross-section. Available in 3 and 4 core, sizes from 25mm² to 95mm². XLPE insulation Type GP8 per BS 7655 1.2. FR PVC bedding, single galvanized SWA, FR PVC Type 9 outer sheath. Suitable for indoor, outdoor, cable trays, ducts, conduit and underground under mechanical stress.
| Specification | Details |
|---|---|
| Conductor | Stranded Compacted Sector Shape Annealed Plain Copper Class 2 per IEC 60228 |
| Insulation | XLPE Type GP8 per BS 7655 1.2 |
| Inner Sheath | FR PVC Black |
| Armour | Single layer galvanized SWA |
| Outer Sheath | FR PVC Type 9 per BS 7655 4.2 – Black |
| Cores | 3, 4 |
| Sizes | 25, 35, 50, 70, 95 mm² |
| 3-core OD range | 23.3mm (25mm²) to 35.9mm (95mm²) |
| 4-core OD range | 26.3mm (25mm²) to 41.6mm (95mm²) |
| Weight | 1483 kg/km (3C/25mm²) to 5356 kg/km (4C/95mm²) |
| Voltage | 600/1000 V |
| Temp | -5°C to 90°C |
| Min Bending Radius | 8x OD |
| Max SC Temp | 250°C (5 sec) |
| Available Sizes / Core Configurations | 3 core: 25, 35, 50, 70, 95 mm² 4 core: 25, 35, 50, 70, 95 mm² |
| Conductor Type | Stranded Compacted Sector Shape Annealed Plain Copper – Class 2 per IEC 60228 |
| Insulation | XLPE Type GP8 per BS 7655 1.2 – 90°C |
| Sheath / Outer Jacket | FR PVC bedding (Black) + SWA + FR PVC Type 9 outer sheath (Black) |
| Voltage Rating | 600/1000 V |
| Standard / Compliance | BS 5467, BS 7655, IEC 60332-1; optional IEC 60332-3 CAT C, UV/Oil resistance |
| Color Code | 3C: Brown/Black/Grey 4C: Blue/Brown/Black/Grey |
| Standard Packing | Drum; standard lengths |
| Typical Applications | High current power distribution, utility networks, industrial plants, switching stations, underground cabling under mechanical stress |
