JG-HE032
Industrial Automation Systems, CNC Machine Control, Manufacturing Equipment, Material Handling, Packaging Machinery, Textile Industry, Food Processing, Pharmaceutical Equipment, Chemical Plants, Power Distribution, Motor Control, Robotics Applications, Conveyor Systems, Process Control, Machine Tools, Heavy Industrial Equipment, Control Cabinets, Factory Automation
JIGO JG-HE032 Heavy Duty Connector Side Open 32 Pin Metal Plug & Socket Bottom Open | Industrial Rectangular Metal Connector Bottom Open Design | Side Entry Cable Connection | IP65 Waterproof Protection Rating | 16A 500V High Current Capacity | Silver-Plated Copper Contact Pins | Die-Cast Aluminum Alloy Shell Grey | Screw Terminal Connection 0.5-4mm² | Metal Roller Double Buckle Locking | Temperature Range -40°C to +125°C | UL94 V0 Flame Retardant | CE/RoHS Certified Quality
Technical Specifications
| Specification | Details |
|---|---|
| Model | JG-HE032 |
| Specification | Side Open 32 Pin Metal Plug & Socket Bottom Open |
| Current Rating | 16A |
| Voltage Rating | 500V |
| Pin Material | Copper silver-plated |
| Contact Resistance | ≤1mΩ |
| Shell Material | Die-cast aluminum alloy |
| Shell Color | Grey |
| Surface Treatment | High-temperature powder coating |
| Wiring Form | Screw link |
| Wire Specification | 0.5-4mm² |
| Screw Torque | 0.5NM |
| Wire Stripping | 7-9mm |
| Plug Number | ≥500 |
| Working Temperature | -40°C to +125°C |
| Shell Materials | Die-casting aluminum alloy |
| Chain Mode | Metal roller, double buckle |
| Shell Surface | High temperature powder coating |
| Original Seal | Nitrile rubber |
| Protection Grade | IP65 |
| Standards | CE/RoHS |
