JG-HE032 (Close)
Harsh Environment Industrial Applications, Outdoor Equipment Control, Weatherproof Systems, Marine Industrial Equipment, Corrosive Environment Protection, Dusty Factory Locations, Wet Processing Areas, Chemical Resistant Systems, Food Processing Hygiene Areas, Pharmaceutical Clean Rooms, Outdoor Material Handling, Weather-Exposed Automation, Sealed Control Panels, Environmental Protection Systems, Washdown Equipment, Clean Manufacturing, Protected Motor Control
JIGO JG-HE032 Heavy Duty Connector Side Closed 32 Pin Metal Plug & Socket Bottom Closed | Industrial Rectangular Metal Connector Fully Sealed Bottom Close | IP65 Enhanced Waterproof Dustproof Environmental Protection | 16A 500V High Current Sealed Configuration | Silver-Plated Copper Pins Corrosion Resistant | Die-Cast Aluminum Sealed Shell Grey | Screw Terminal Sealed Connection 0.5-4mm² | Metal Double Buckle Secure Locking | Extended Temperature Range -40°C to +125°C | UL94 V0 Flame Retardant | CE/RoHS Certified
Technical Specifications
| Specification | Details |
|---|---|
| Model | JG-HE032 Bottom Close |
| Specification | Side Closed 32 Pin Metal Plug & Socket Bottom Closed |
| Current | 16A |
| Voltage | 500V |
| Pin | Copper silver-plated sealed |
| Resistance | ≤1mΩ |
| Shell | Sealed aluminum alloy |
| Color | Grey sealed |
| Surface | High-temp powder coat sealed |
| Wiring | Screw sealed |
| Wire | 0.5-4mm² |
| Torque | 0.5NM |
| Stripping | 7-9mm |
| Insertions | ≥500 |
| Temperature | -40 to +125°C |
| Seal | Enhanced nitrile rubber |
| Chain | Metal roller double buckle |
| Protection | IP65 enhanced |
| Flame | UL94 V0 |
| Cert | CE/RoHS |
