1600x800x400
Industrial Electrical Distribution, Switchgear Housing, Control Panel Cabinets, Motor Control Centers, Factory Automation Equipment, Process Control Systems, Building Management Panels, Power Distribution Boards, HVAC Control Cabinets, Pump Control Stations, Manufacturing Equipment Housing, Industrial Control Systems, Electrical Distribution Assemblies, Commercial Electrical Systems, Industrial Plant Equipment, Automation Control Panels
RR Kabel Metal Enclosure IP65 1600x800x400mm (WxHxD) Large Capacity | Weatherproof Industrial Cabinet RAL 7032 Light Grey | Electro-Galvanized Steel Sheet Body 1.5mm | Matt-Finish Polyester Powder Coated | Hot Dip Galvanized Mounting Plate 2mm | IP65 Waterproof Dustproof Protection | Corner Formed Door Enhanced Sealing | CNC Machine Formed Polyurethane Gasket | Removable Gland Plate Bottom Entry | Earthing Studs Door & Enclosure | Heavy Duty Industrial Construction | IEC 60529/62208 Standards Compliant | CE Certified Quality | Volume: 512.0L | Popular Size
Technical Specifications
| Specification | Details |
|---|---|
| Model | 1600x800x400mm |
| Dimensions | W1600 x H800 x D400mm |
| Body Material | Electro-galvanized steel sheet |
| Body Thickness | 1.5mm |
| Door Thickness | 1.5mm |
| Mounting Plate | Hot dip GI steel 2mm |
| Surface Finish | Matt polyester powder coating |
| Color | RAL 7032 light grey |
| Protection Rating | IP65 |
| Gasket | CNC formed polyurethane |
| Door Type | Corner formed |
| Gland Plate | Removable bottom |
| Earthing | Studs on door & body |
| Volume Capacity | 512.0 liters |
| Impact Rating | IK10 |
| Standards | IEC 60529, IEC 62208 |
| Certification | CE |
| Operating Temp | -25°C to +70°C |
| Humidity | Up to 95% RH |
